| 规格 Specification | |
| 系统 System | |
| 处理器 Processor | Intel® 6th/7th Gen. Core™ i3/i5/i7, Pentium®, Celeron® processor, LGA1151 Socket |
| 芯片 Chipset | Intel® H110 Chipset |
| 内存 Memory | DDR3L 1333/1600MHz, 2 x UDIMM Slot, up to 16GB |
| 图形 Graphics | Intel® HD Graphics, dual display |
| 存储 Storage | 3 x SATA 3.0, 1 x mSATA |
| 操作系统 OS | Windows 7/8/10, Linux |
| 外部接口 External I/O | |
| 网口 Ethernet | 1 x Intel® I211AT GbE (10/100/1000 Mbps) , 1 x Intel® I219LM GbE (10/100/1000 Mbps) |
| 显示 Video | 1 x VGA: max resolution up to 1920 x 1200@60Hz 1 x HDMI: max resolution up to 2560 x 1600@60Hz |
| 音频 Audio | 1 x Line-out, 1 x Mic-in |
| 串口 COM | 2 x RS232/422/485 with Atuo Flow |
| USB | 4 x USB 2.0 (USB SR Pro supported), 4 x USB 3.0 (USB SR Pro supported) |
| 按钮 Button | 1 x Power Button, 1 x Reset Button |
| 指示灯 LED | 1 x Power LED, 1 x HDD LED |
| 内部接口 Internal I/O | |
| 扩展接口 Expansion | 1 x PCIe X 16, 1 x PCIe X 4, 2 x PCI |
| USB | 1 x USB 2.0 (Type A), 1 x USB 2.0 pin header |
| 串口 COM | 8 x RS232 pin header |
| GPIO | 1 x 16bit GPIO |
| SATA | 3 x SATA 3.0 |
| LPT | 1 x LPT pin header |
| PS/2 | 1 x PS/2 pin header |
| 风扇 FAN | 1 x CPU Fan pin header, 1 x System Fan pin header |
| 环境 Environmental | |
| 操作温度 Operating Temp. | 0℃~ 40℃ |
| 操作温度 Operating Temp.. | -20℃~ 60℃ |
| 湿度Relative Humidity | 5% ~ 95%, 非凝结状态 Non-condensing |
| 电源 Power | |
| 电源输入 Power Input | 100~240V(AC) |
| 电源功耗 Power Watt | 250W |
| 机构 Mechanical | |
| 外观 Housing | SGCC |
| 安装方式 Mounting | 桌面式 (Desk-Mount) |
| 尺寸 Dimension | 366.3 (L)x 330 (W) x 176 (H)mm |
| 重量 Weight | 9kg(约) |
| 认证 Certification | |
| 安规认证 Safety Certification | CCC |
